National Instruments 60 Series Programmer's Manual

Chapter 3 Register Map and Descriptions
PCI E Series RLPM 3-10
© National Instruments Corporation
PCI-MIO-16XE-10, PCI-6031E, PCI-6032E, and
PCI-6033E and should be set to 1. Dither cannot be
disabled on the PCI-MIO-16XE-50, PCI-MIO-16XE-10,
PCI-6031E, PCI-6032E, and PCI-6033E.
8 Unip/Bip Channel Unipolar/Bipolar—This bit configures the ADC
for unipolar or bipolar mode. When Unip/Bip is set, the
ADC is configured for unipolar operation and values read
from the ADC Data Register are in straight binary format.
When Unip/Bip is clear, the ADC is configured for bipolar
operation and values. The data values are two’s
complement and automatically sign extended.
2–0 Gain<2..0> Channel Gain Select 2 through 0—These three bits control
the gain settings of the input PGIA for the selected analog
channel. The gains shown in Table 3-3 can be selected on
the PCI E Series boards.
Table 3-3. PGIA Gain Selection
Gain<2..0> Actual Gain
000 0.5
1,2
001 1
010 2
3
011 5
1, 3
100 10
101 20
1, 3
110 50
1, 3
111 100
1
Not supported on the PCI-MIO-16XE-50
2
Not supported on the PCI-MIO-16XE-10, PCI-6031E, PCI-6032E,
and PCI-6033E
3
Not supported on the PCI-6023E, PCI-6024E, and PCI-6025E.
