National Instruments 60 Series Programmer's Manual

Chapter 3 Register Map and Descriptions
© National Instruments Corporation 3-13 PCI E Series RLPM
Table 3-5. Differential Channel Assignments
Chan Type<2..0> = DIFF
Chan<3..0> PGIA(+) PGIA(–)
0000 ACh0 ACh8
0001 ACh1 ACh9
0010 ACh2 ACh10
0011 ACh3 ACh11
0100 ACh4 ACh12
0001 ACh5 ACh13
0110 ACh6 ACh14
0111 ACh7 ACh15
1xxx Reserved Reserved
Table 3-6. Nonreferenced Single-Ended Channel Assignments
Chan Type<2..0> = NRSE
Chan<3..0> PGIA(+) PGIA(–)
0000 ACh0 AISense
0001 ACh1 AISense
0010 ACh2 AISense
0011 ACh3 AISense
0100 ACh4 AISense
0101 ACh5 AISense
0110 ACh6 AISense
0111 ACh7 AISense
1000 ACh8 AISense
1001 ACh9 AISense
1010 ACh10 AISense
1011 ACh11 AISense
