National Instruments cRIO-9068 - Page 22

1
2
3
4
3
4
1. Use a #1 Phillips screwdriver to remove the two screws from the back of the chassis on
the front-panel side.
2. Use the screwdriver and the two M3x20 screws to attach the adapter bracket to the
chassis.
3. Align one of the end brackets with the mounting hole at one of the ends of the chassis.
22 | ni.com | NI cRIO-9068 User Manual
