Appendix A Device-Specific Information
© National Instruments Corporation A-61 M Series User Manual
NI 6250
PCI/PXI-6250 Pinout
Figure A-27 shows the pinout of the PCI/PXI-6250.
For a detailed description of each signal, refer to the I/O Connector Signal
Descriptions section of Chapter 3, Connector and LED Information.
Note M Series devices may be used with most E Series accessories. However, some
E Series accessories use different terminal names. Refer to the M Series and E Series
Pinout Comparison section of Chapter 3, Connector and LED Information, for more
information.
