Appendix A Device-Specific Information
M Series User Manual A-86 ni.com
NI 6254
PCI/PXI-6254 Pinout
Figure A-40 shows the pinout of the PCI/PXI-6254. The I/O signals appear
on two 68-pin connectors.
For a detailed description of each signal, refer to the I/O Connector Signal
Descriptions section of Chapter 3, Connector and LED Information.
Note M Series devices may be used with most E Series accessories. However, some
E Series accessories use different terminal names. Refer to the M Series and E Series
Pinout Comparison section of Chapter 3, Connector and LED Information, for more
information.
