National Instruments M Series User Manual

Chapter 3 Connector and LED Information
M Series User Manual 3-4 ni.com
CHS GND
*
— — Chassis Ground
*
—This terminal connects to the
USB-62xx BNC device metal enclosure. You can connect
your cable’s shield wire to CHS GND for a ground
connection.
NC — — No connect—Do not connect signals to these terminals.
*
USB-62xx Screw Terminal users can connect the shield of a shielded cable to the chassis ground lug for a ground
connection. The chassis ground lug is not available on all device versions.
Table 3-1. I/O Connector Signals (Continued)
Signal Name Reference Direction Description
