NI Digital Multimeters Getting Started Guide 18 ni.com
2-Wire Resistance
Figure 14. NI 4050 Signal Connections for 2-Wire Resistance Measurements
Figure 15. NI 4060, NI 4065, and NI 407x Signal Connections for 2-Wire Resistance Measurements
1 NI 4060 2 NI PXI/PCI/PCIe-4065 and NI 407x 3 NI USB-4065
250 V
MAX.
LO
HI
2
3
1
