NI Digital Multimeters Getting Started Guide 30 ni.com
NI 4065
1. Remove all front panel connections from the NI 4065.
• (NI PXI/PCI/PCIe-4065) Power down the chassis, and remove the device.
•
(NI USB-4065) Disconnect the USB cable from the NI USB-4065.
2. Locate the fuse holder on the NI 4065.
•
(NI PXI-4065) View the device at the angle shown in Figure 25.
•
(NI PCI/PCIe-4065) View the device at the angle shown in Figure 26.
• (NI USB-4065) View the device at the angle shown in Figure 27.
Figure 25. Locating the Fuse on the NI PXI-4065
1 Fuse Holder
1
