1 Injector/EjectorHandle(InDown
Position)
2 PXISerialBoard
3 PXIChassis
4 Injector/EjectorRail
InstallingthePXISerialBoard
6. ScrewthePXIserialboardfrontpaneltothefrontpanelmounting
railofthePXIorCompactPCIchassis.
7. TurnonyourPXIorCompactPCIchassis.
8. Theoperatingsystemwillautomaticallydetectyourhardware.
Theserialhardwareinstallationiscomplete.ContinuetoVerifythe
Installation.
