X Series User Manual

CTR 2 A 11 (PFI 0)

CTR 2 Z 10 (PFI 1)

CTR 2 B 43 (PFI 2)

CTR 3 SRC 6 (PFI 5)

CTR 3 GATE 5 (PFI 6)

CTR 3 AUX 38 (PFI 7)

CTR 3 OUT 39 (PFI 15)

CTR 3 A 6 (PFI 5)

CTR 3 Z 5 (PFI 6)

CTR 3 B 38 (PFI 7)

FREQ OUT 1 (PFI 14)

Table 7-10. X Series USB Screw Terminal Device Default

NI-DAQmx Counter/Timer Pins

Counter/Timer Signal Default Pin Number (Name)

CTR 0 SRC 81 (PFI 8)

CTR 0 GATE 83 (PFI 9)

CTR 0 AUX 85 (PFI 10)

CTR 0 OUT 89 (PFI 12)

CTR 0 A 81 (PFI 8)

CTR 0 Z 83 (PFI 9)

CTR 0 B 85 (PFI 10)

CTR 1 SRC 76 (PFI 3)

CTR 1 GATE 77 (PFI 4)

CTR 1 AUX 87 (PFI 11)

CTR 1 OUT 91 (PFI 13)

Table 7-9. X Series PCI Express/PXI Express/USB Mass Termination/USB BNC Device

Default NI-DAQmx Counter/Timer Pins (Continued)

Counter/Timer Signal Default Connector 0 Pin Number (Name)
