RMC-8357 User Manual
Installing the Slide Mounting Brackets in the Rack
Install the slide mounting brackets in the rack as shown in Figure 2-2.
Figure 2-2. Installing Slide Mounting Brackets in Rack
1 Retaining Screw (x4)
2 Slide Mounting Bracket (x4)
3 Washer (x8)
4 Nut (x4)
1
2
4
3
