© National Instruments | 3-1
3
I/O Information
This chapter describes the RMC-8357 I/O connectors.
Front Panel Connectors
Table 3-2 lists various peripherals and their corresponding RMC-8357 external connectors,
bus interfaces, and functions.
Rear Panel Connectors
Table 3-2 lists various peripherals and their corresponding RMC-8357 external connectors,
bus interfaces, and functions.
Table 3-1. RMC-8357 Front Panel Peripherals Overview
Peripheral External Connector Description
USB USB 4-pin Series A stacked receptacle USB 3.0 capable
Table 3-2. RMC-8357 Rear Panel Peripherals Overview
Peripheral External Connector Description
Keyboard USB USB-style keyboard
Mouse USB USB-style mouse
USB USB 4-pin Series A stacked receptacles USB 2.0 capable
USB USB 4-pin Series A stacked receptacles USB 3.0 capable
IPMI IPMI dedicated LAN Not supported
Serial COM1 (9-pin DSUB)
COM2 (9-pin DSUB)
16550 RS-232 serial ports
Video VGA (15-pin DSUB) Onboard graphics controller
Ethernet LAN (RJ45) 10/100/1000 Ethernet
connection
Ethernet LAN (RJ45) 10/100/1000 Ethernet
connection
