Chapter 1 Introduction
© National Instruments Corporation 1-3 SCB-68 Shielded Connector Block User Manual
NI 6024E for PCMCIA
(DAQCard-6024E),
NI 6036E for PCMCIA
(DAQCard-6036E),
NI 6062E for PCMCIA
(DAQCard-6062E)
SCH68-68-EP,
RC68-68
Direct feedthrough only
Thermocouple measurements
Open thermocouple detection
Current input
Filtering
Voltage dividers
AC coupling
NI 6012E for PCMCIA
(DAQCard-AI-16XE-50),
NI 6041E for PCMCIA
(DAQCard-AI-16E-4)
PSHR68-68,
PR68-68F
Direct feedthrough only
Thermocouple measurements
Open thermocouple detection
Current input
Filtering
Voltage dividers
AC coupling
Analog Output (AO) Devices
NI 670X
for PCI/PXI/CompactPCI
SH68-68-D1
R6868
Direct feedthrough only
RC filtering
NI 671X/673X
for PCI/PXI/CompactPCI
SH68-68-EP
SH68-68-R1-EP
R6868
Direct feedthrough only
RC filtering
NI 6715 for PCMCIA
(DAQCard-6715)
SHC68-68-EP
RC6868
Direct feedthrough only
RC filtering
Digital I/O (DIO) Devices
NI 6533
for ISA/PCI/PXI/CompactPCI
SH68-68-D1
R6868
Direct feedthrough only
NI 6533 for PCMCIA
(DAQCard-6533),
PSHR68-68-D1,
PR6868F
Direct feedthrough only
NI 6534
for PCI/PXI/CompactPCI
SH68-68-D1
R6868
Direct feedthrough only
Real-Time (RT) Devices
NI 7030/6030E
for PCI/PXI/CompactPCI,
NI 7030/6040E
for PCI/PXI/CompactPCI
SH68-68-EP
SH68-68R1-EP,
R6868
Direct feedthrough only
Thermocouple measurements
Open thermocouple detection
Current input
Filtering
Voltage dividers
AC coupling
NI 7030/6533
for PCI/PXI/CompactPCI
SH68-68-D1
R6868
Direct feedthrough only
Table 1-1. Device-Specific Hardware Configuration (Continued)
Device Cable Assembly Features
