National Instruments SCB-68 User Manual

Chapter 2 Parts Locator and Wiring Guide
SCB-68 Shielded Connector Block User Manual 2-4 ni.com
Table 2-1. Switch Configurations and Affected Signals
Switch Setting Applicable Signals
Direct feedthrough, with temperature sensor disabled and
accessory power disabled
Analog input, analog output,
digital I/O, and timing I/O
Temperature sensor disabled, and accessory power enabled
2
Note: This configuration is the factory-default configuration.
Analog input
and analog output
1
S1
S2
S5 S4 S3
Signal Conditioning
Circuitry Power (Off)
Temperature Sensor
S1
S2
S5 S4 S3
Temperature Sensor
Signal Conditioning
Circuitry Power (On)
