Chapter D SCB-68 Circuit Diagrams
© National Instruments Corporation D-3 SCB-68 Shielded Connector Block User Manual
Figure D-4. Analog Output Circuitry
RC3
DAC0OUT
(I/O Pin 22)
R3
AOGND
(I/O Pin 55)
RC2
DAC1OUT
(I/O Pin 21)
R2
DAC1OUT Screw Terminal
AOGND
(I/O Pin 54)
AOGND Screw Terminal
AOGND Screw Terminal
DAC0OUT Screw Terminal
