Chapter 2 Configuration and Installation

SCXI-1120/D User Manual 2-8 www.natinst.com

Analog Configuration

The SCXI-1120/D has 42 analog configuration jumpers.

Notice that the jumper configurations for each channel are similar; only the

jumper reference designator number changes.

Grounding, Shielding, and Reference-Mode

Selection

Jumper W46

Note

The SCXI-1120/D will drive pins 4, 6, 8, 10, 12, 14, 16, and 18 on the rear signal

connector, although the SCXI-1120/D is in multiplexed mode.

W44 Connects SLOT0SEL* to the

SCXIbus INTR* line after

buffering (factory-default

setting). Applies to Revision A

and B of the SCXI-1120

modules only.

W45 Factory-default setting

Table 2-1.

Digital Signal Connections, Jumper Settings (Continued)

Jumper Description Configuration
