NAPI112B
Power Supply Distribution PWB Assy
REFDES NAUTEL #DESCRIPTION VENDOR # OEM CODE
C01 CCG07Capacitor, Ceramic, 0.1uF 10%100V CKR06BX104KRV 56289
C02 CCG07Capacitor, Ceramic, 0.1uF 10%100V CKR06BX104KRV 56289
C03 CCG01Capacitor, Ceramic, 0.001uF 10% 200V CKR05BX102KRV
SPRAGUE
91929
C04 CCG07Capacitor, Ceramic, 0.1uF 10%100V CKR06BX104KRV 56289
C05 CCG07Capacitor, Ceramic, 0.1uF 10%100V CKR06BX104KRV 56289
C06 CCG01Capacitor, Ceramic, 0.001uF 10% 200V CKR05BX102KRV
SPRAGUE
91929
C07 CCG01Capacitor, Ceramic, 0.001uF 10% 200V CKR05BX102KRV
SPRAGUE
91929
C08 CCG09Capacitor, Ceramic, 0.47uF 10% 50V CKR06BX474KRV 56289
C09 CCG01Capacitor, Ceramic, 0.001uF 10% 200V CKR05BX102KRV
SPRAGUE
91929
C10 CCG09Capacitor, Ceramic, 0.47uF 10% 50V CKR06BX474KRV 56289
C11 CCG01Capacitor, Ceramic, 0.001uF 10% 200V CKR05BX102KRV
SPRAGUE
91929
C12 CCG07Capacitor, Ceramic, 0.1uF 10%100V CKR06BX104KRV 56289
C13 CCG09Capacitor, Ceramic, 0.47uF 10% 50V CKR06BX474KRV 56289
C14 CCG01Capacitor, Ceramic, 0.001uF 10% 200V CKR05BX102KRV
SPRAGUE
91929
C15 CCG09Capacitor, Ceramic, 0.47uF 10% 50V CKR06BX474KRV 56289
C16 CCG07Capacitor, Ceramic, 0.1uF 10%100V CKR06BX104KRV 56289
C17 CCG04Capacitor, Ceramic, 0.01uF 10% 100V CKR05BX103KRV 56289
CR01 UR93Diode, Pwr Rect, Schottky, 60VDual 2x40A STPS80L60CY(Static)(
RoHS)
STMicroelectronics
CR02 UR93Diode, Pwr Rect, Schottky, 60VDual 2x40A STPS80L60CY(Static)(
RoHS)
STMicroelectronics
CR03 UR93Diode, Pwr Rect, Schottky, 60VDual 2x40A STPS80L60CY(Static)(
RoHS)
STMicroelectronics
CR04 UR93Diode, Pwr Rect, Schottky, 60VDual 2x40A STPS80L60CY(Static)(
RoHS)
STMicroelectronics
E01 HAC55Terminal,PC Screw 10-32,30 Amp 7787 KEYSTONE
E02 HAC55Terminal,PC Screw 10-32,30 Amp 7787 KEYSTONE
E03 HAC55Terminal,PC Screw 10-32,30 Amp 7787 KEYSTONE
E04 HAC55Terminal,PC Screw 10-32,30 Amp 7787 KEYSTONE
E05 HAC55Terminal,PC Screw 10-32,30 Amp 7787 KEYSTONE
E06 HAC55Terminal,PC Screw 10-32,30 Amp 7787 KEYSTONE
E07 HAC55Terminal,PC Screw 10-32,30 Amp 7787 KEYSTONE
E08 HAC55Terminal,PC Screw 10-32,30 Amp 7787 KEYSTONE
E09 HAC55Terminal,PC Screw 10-32,30 Amp 7787 KEYSTONE
E10 HAC55Terminal,PC Screw 10-32,30 Amp 7787 KEYSTONE
J01 JU25MTA, Keyed Square Post HeaderAssy, 4 pin 647123-4 00779
Page 73 of 82
NAPI112B
