Continued from previous page
NAPI112B
Power Supply Distribution PWB Assy
REFDES NAUTEL #DESCRIPTION VENDOR # OEM CODE
J02 JU25MTA, Keyed Square Post HeaderAssy, 4 pin 647123-4 00779
J03 JU25MTA, Keyed Square Post HeaderAssy, 4 pin 647123-4 00779
J04 JU25MTA, Keyed Square Post HeaderAssy, 4 pin 647123-4 00779
J05 JU25MTA, Keyed Square Post HeaderAssy, 4 pin 647123-4 00779
J06 JU25MTA, Keyed Square Post HeaderAssy, 4 pin 647123-4 00779
J07 JP46Conn, Header, Ribbon Cbl, 20 pin 499910-4 00779
J08 JP46Conn, Header, Ribbon Cbl, 20 pin 499910-4 00779
J09 JM44Conn, Jack, RJ45, PWB Mount 556591-1 09482
J10 JM44Conn, Jack, RJ45, PWB Mount 556591-1 09482
J11 JM44Conn, Jack, RJ45, PWB Mount 556591-1 09482
J12 JM44Conn, Jack, RJ45, PWB Mount 556591-1 09482
J13 JM44Conn, Jack, RJ45, PWB Mount 556591-1 09482
Q01 QR52Transistor, FET, N Channel, Plas IRF540N(STATIC) 81483
R01 RAC01Resistor, MF, 100K Ohms, 1PC 1/4W MF1/4DL1003F 59124
R02 RD11Resistor, Film, 22K ohms, 2PC1/2W RL20S223G 35005
R03 RD11Resistor, Film, 22K ohms, 2PC1/2W RL20S223G 35005
R04 RAC01Resistor, MF, 100K Ohms, 1PC 1/4W MF1/4DL1003F 59124
R05 RAB37Resistor, MF, 10.0K Ohms, 1PC1/4W MF1/4DL1002F 59124
R06 RAB26Resistor, MF, 1.21K Ohms, 1PC1/4W MF1/4DL1211F 59124
R07 RAC01Resistor, MF, 100K Ohms, 1PC 1/4W MF1/4DL1003F 59124
R08 RAB37Resistor, MF, 10.0K Ohms, 1PC1/4W MF1/4DL1002F 59124
R09 RAB26Resistor, MF, 1.21K Ohms, 1PC1/4W MF1/4DL1211F 59124
R10 RAB37Resistor, MF, 10.0K Ohms, 1PC1/4W MF1/4DL1002F 59124
R11 RAB26Resistor, MF, 1.21K Ohms, 1PC1/4W MF1/4DL1211F 59124
R12 RAB25Resistor, MF, 1K Ohms, 1PC 1/4W MF1/4DL1001F 59124
R13 RAB41Resistor, MF, 22.1K Ohms, 1PC1/4W MF1/4DL2212F 59124
R14 RAB25Resistor, MF, 1K Ohms, 1PC 1/4W MF1/4DL1001F 59124
TP01 HR10Terminal, Test Point, PWB,Yellow TP-106-01-04 COMP-C
TP02 HR10Terminal, Test Point, PWB,Yellow TP-106-01-04 COMP-C
TP03 HR10Terminal, Test Point, PWB,Yellow TP-106-01-04 COMP-C
TP04 HR10Terminal, Test Point, PWB,Yellow TP-106-01-04 COMP-C
TP05 HR10Terminal, Test Point, PWB,Yellow TP-106-01-04 COMP-C
TP06 HR10Terminal, Test Point, PWB,Yellow TP-106-01-04 COMP-C
Page 74 of 82
NAPI112B
