NV5/NV3.5 Troubleshooting Manual Wiring/connector lists
Page 4-4 Issue 3.2 2014-12-10
TB2-2B4 DS1-X2 34 White 14
TB2-3B4 DS2-X1 35 Red 14
TB3-1B4 DS2-X2 36 White 14
TB3-2B4 DS3-X1 37 Red 14
TB3-3B4 DS3-X2 38 White 14
-- 39 Not Used
E1 E5 40 Black 2 Station Ref Gnd
E1 E5 41 Black 2 Station Ref Gnd
E6 E7 - Grn/Yel 14 Jumper
A7E7 E14-A 42 White 16
A7E8 E15-A 43 White 16
U1-6 (+V) A7E4 44 White 18
U1-7 (+V) A7E4 45 White 18
U1-4 (-V) A7E6 46 Black 18
U1-5 (-V) A7E6 47 Black 18
U1-5 (-V) U1-3 (GND) - Black 18 Jumper
U2-6 (+V) A7E5 48 White 18
U2-7 (+V) A7E5 49 White 18
U2-4 (-V) A7E6 50 Black 18
U2-5 (-V) A7E6 51 Black 18
U2-5 (-V) U2-3 (GND) - Black 18 Jumper
A7E7 E10-A 52 White 16
A7E8 E11-A 53 Black 16
E10-B P9 (+VE) - White 18
E10-B P8-4 54 White 18
E11-B P9 (-VE) - Black 18
E11-B P8-1 55 Black 18
U3-4 (V1) P7-1 56 White 22
U3-1 (V2) P7-4 57 White 22
U3-5 (V3) P7-7 58 White 22
U3-2 (COM) P7-3 59 Black 22
U3-2 (COM) U3-6 (GND) - Black 22 Jumper
U4-4 (V1) P7-2 60 White 22
U4-1 (V2) P7-5 61 White 22
U4-5 (V3) P7-8 62 White 22
U4-2 (COM) P7-6 63 Black 22
U4-2 (COM) U4-6 (GND) - Black 22
Table 4.3: Wiring List - NV5/NV3.5 Transmitter
Source Destination Wire # Colour Size Remarks
