NV5/NV3.5 Troubleshooting Manual Wiring/connector lists
Issue 3.2 2014-12-10 Page 4-5
P10-1 P11-1 64 White 24
P10-2 P11-2 65 Black 24
P12-1 P13-1 66 White 20
P12-2 P13-2 67 White 20
P12-3 P13-3 68 Black 20
P12-4 P13-4 69 Black 20
P16-1 P17-1 70 White 22
P16-2 P17-2 71 White 22
P16-3 P17-3 72 Black 22
P16-4 P17-4 73 Black 22
A8E1 A7E1 74 White 10
A9E1 A7E2 75 White 10
A10E1 CR1-A1 76 White 10
A11E1 CR1-A2 77 White 10
CR1-K1 (A) A17E10 78 White 10
A19E1 A17E15 79 White 10
A20E1 A17E16 80 White 10
A22E1 A17E11 81 White 10
A23E1 A17E12 82 White 10
- - 83 Not Used
- - 84 Not Used
- - 85 Not Used
- - 86 Not Used
-- 87 Not Used
-- 88 Not Used
-- 89 Not Used
TB3-2B4 P1-L 90A Brown or Black 18
TB3-3B4 P1-N 90B Blue or White 18
P1-E GND 90C Grn or Grn/Yel 18
P2-L U1-1 (L) 91A Brown 18
P2-N U1-2 (N) 91B Blue 18
P2-E U1-3 (GND) 91C Grn/Yllw 18
P3-L U3-8 (L) 92A Brown 18
P3-N U3-7 (N) 92B Blue 18
P3-E U3-6 (GND) 92C Grn/Yel 18
TB2-1B3 P4-L 93A Brown or Black 18
TB2-2B3 P4-N 93B Blue or White 18
Table 4.3: Wiring List - NV5/NV3.5 Transmitter
Source Destination Wire # Colour Size Remarks
