NV5/NV3.5 Troubleshooting Manual Wiring/connector lists
Page 4-6 Issue 3.2 2014-12-10
P4-E GND 93C Grn or Grn/Yllw 18
P5-L U2-1 (L) 94A Brown 18
P5-N U2-2 (N) 94B Blue 18
P5-E U2-3 (GND) 94C Grn/Yllw 18
P6-L U4-8 (L) 95A Brown 18
P6-N U4-7 (N) 95B Blue 18
P6-E U4-6 (GND) 95C Grn/Yllw 18
U3-4 P7-1 96 White 22
U4-4 P7-2 97 White 22
-- 98 Not Used
-- 99 Not Used
A7E9 E12-A 100 White 16
A7E10 E13-A 101 Black 16
E12-B P24-1 102 White 22
E12-B P25-1 103 White 22
-- 104 Not Used
-- 105 Not Used
E13-B P24-3 106 Black 22
E13-B P25-3 107 Black 22
-- 108 Not Used
-- 109 Not Used
A8J1-45 GND - Grn/Yel 14 Jumper
A9J1-45 GND - Grn/Yel 14 Jumper
A10J1-45 GND - Grn/Yel 14 Jumper
A11J1-45 GND - Grn/Yel 14 Jumper
A19J1-45 GND - Grn/Yel 14 Jumper
A20J1-45 GND - Grn/Yel 14 Jumper
A22J1-45 GND - Grn/Yel 14 Jumper
A23J1-45 GND - Grn/Yel 14 Jumper
A25J1-45 GND - Grn/Yel 14 Jumper
A26J1-45 GND - Grn/Yel 14 Jumper
A28J1-45 GND - Grn/Yel 14 Jumper
A29J1-45 GND - Grn/Yel 14 Jumper
W1P1 W1P2 W1 Coax -
W2P1 W2P2 W2 Coax -
W3P1 W3P2 W3 CAT-5e -
W4P1 W4P2 W4 CAT-5e -
Table 4.3: Wiring List - NV5/NV3.5 Transmitter
Source Destination Wire # Colour Size Remarks
