NV5/NV3.5 Troubleshooting Manual Wiring/connector lists
Page 4-8 Issue 3.2 2014-12-10
Table 4.4: Connector Mating Information - NV5/NV3.5 Transmitter
Connector Mate Remarks
A14B1P1 A15J4 REJ LD A FAN 1
A14B2P1 A15J5 REJ LD A FAN 2
A14W1P1 A15J2 REJ LD A PWR SAMPLES
A100W1P1 A100J3 used only when A100 is installed
A100W1P2 A6J1 used only when A100 is installed
A100W2P1 A100J4 used only when A100 is installed
A100W2P2 A6J5 used only when A100 is installed
B1P1 P24 DOOR BLOWER 1 - PLUG 1
B1P2 P25 DOOR BLOWER 1 - PLUG 2
B2P1 Not Used
B1P2 Not Used
P1 A6J1 AC DIST. INPUT A
P2 A6J2 AC DIST. OUTPUT +12V PS A
P3 A6J3 AC DIST. OUTPUT LVPS A
P4 A6J5 AC DIST. INPUT B
P5 A6J6 AC DIST. OUTPUT +12V PS B
P6 A6J7 AC DIST. OUTPUT LVPS B
P7 A1J11 CONTROL PWB LVPS
P8 U6U1-CN4 SBC +12V
P9 U5-DC INPUT MONITOR +12V
P10 A1J7 SBC WD RESET
P11 U6U1-RST1 SBC WD RESET (RHS connector)
P12 A7J5 FAN VOLTS (REJ LD A)
P13 A15J3 FAN VOLTS (REJ LD A)
P14 Not Used
P15 Not Used
P16 A7J1 FAN VOLTS (1-4)
P17 A17J9 FAN VOLTS (1-4)
P18 Not Used
P19 Not Used
P20 Not Used
P21 Not Used
P22 Not Used
P23 Not Used
P24 B1P1 DOOR BLOWER 1 - PLUG 1
P25 B1P2 DOOR BLOWER 1 - PLUG 2
P26 Not Used
P27 Not Used
