NV5/NV3.5 Troubleshooting Manual Wiring/connector lists
Issue 3.2 2014-12-10 Page 4-9
Connector Mate Remarks
U5-VGA U6U1-VGA1 AUI VGA
U5-COM U6W2P2 AUI COM
U5-DC INPUT P9 AUI DC INPUT
U6B1P1 U6U1-FAN1 SBC FAN
U6W1P1 U6U1-COM2 SBC Streaming Bus
U6W1P2 W16P2 SBC Streaming Bus
U6W2P1 U6U1-COM3 SBC External Serial
U6W2P2 U5-COM SBC External Serial
W1P1 A3-RF OUT EXCITER A - RF OUT (A3A2J1)
W1P2 A5A1J1 EXCITER A - RF OUT
W2P1 A4-RF OUT EXCITER B, if installed
W2P2 A5A1J2 EXCITER B - RF OUT
W3P1 A1J5 EXCITER A - XMTR LINK
W3P2 A3-XMTR LINK EXCITER A - XMTR LINK (A3A1J2)
W4P1 A1J6 EXCITER B - XMTR LINK
W4P2 A4-XMTR LINK EXCITER B - XMTR LINK (A4A1J2), if installed
W5P1 A13A4J1 EXCITER A - XMTR RF SAMPLE
W5P2 A3-XMTR RF SAMPLE EXCITER A - XMTR RF SAMPLE (A3A1J1)
W6P1 A13A5J1 EXCITER B - XMTR RF SAMPLE
W6P2 A4-XMTR RF SAMPLE EXCITER B, if installed
W7P1 A6J4 EXCITER A - AC
W7P2 A3-AC INPUT EXCITER A - AC (A3U1)
W8P1 A6J8 EXCITER B - AC
W8P2 A4-AC INPUT EXCITER B, if installed
W9P1 A1J4 RF DRV S/C
W9P2 A5A1J3 RF DRV S/C
W10P1 A1J1 BUS - SOURCE
W10P2 A17J14 BUS - 1
W10P3 A17J10 BUS - 2
W11P1 A15J1 REJ LD SAMPLE A
W11P2 A1J2 REJ LD SAMPLE A
W12 Not Used
W13P1 A7J7 IPA PS DIST.
W13P2 A1J3 IPA PS DIST.
W14P1 A7J8 FAN PS DIST.
W14P2 A1J10 FAN PS DIST.
W15P1 A1J12 SBC LAN
W15P2 U6U1J1 SBC LAN
W16P1 A1J13 SBC Streaming Bus
W16P2 U6W1P2 SBC Streaming Bus
Table 4.4: Connector Mating Information - NV5/NV3.5 Transmitter
