Nautel NV5 - Page 162

NV5/NV3.5 Troubleshooting Manual Wiring/connector lists
Page 4-10 Issue 3.2 2014-12-10
Connector Mate Remarks
W17P1 A1J17 SBC External Serial
W17P2 U6-COM1 SBC External Serial
W18 Not Used
W19 Not Used
W20P1 A13A1J1 FWD PWR SAMPLE
W20P2 A1J18 FWD PWR SAMPLE
W21P1 A13A2J1 REFLD PWR SAMPLE
W21P2 A1J19 REFLD PWR SAMPLE
W22P1 A13A3J1 RF MONITOR
W22J1 -
W23P1 A7J12 FAN PS A CTRL
W23P2 A8J2 FAN PS A CTRL
W24P1 A7J13 FAN PS B CTRL
W24P2 A9J2 FAN PS B CTRL
W25P1 A7J9 IPA PS A CTRL
W25P2 A10J2 IPA PS A CTRL
W26P1 A7J10 IPA PS B CTRL
W26P2 A11J2 IPA PS B CTRL
W27 Not Used
W28P1 A17J17B PS 1A CTRL
W28P2 A19J2 PS 1A CTRL
W29P1 A17J17A PS 1B CTRL
W29P2 A20J2 PS 1B CTRL
W30P1 A5A2J1 RF DRIVE 1
W30P2 A17J15 RF DRIVE 1
W31P1 A17J13B PS 2A CTRL
W31P2 A22J2 PS 2A CTRL
W32P1 A17J13A PS 2B CTRL
W32P2 A23J2 PS 2B CTRL
W33P1 A5A2J2 RF DRIVE 2
W33P2 A17J11 RF DRIVE 2
W34P1 A16J5 REJ LD 1-2
W34P2 A14J1 REJ LD 1-2
Table 4.4: Connector Mating Information - NV5/NV3.5 Transmitter
