NV5/NV3.5 Troubleshooting Manual Wiring/connector lists
Page 4-12 Issue 3.2 2014-12-10
Table 4.6: Connector Mating Information - NAE104A & /01 NVE50 Exciter
Connector Mate Remarks
P1 U1-L
P2 U1-N
P3 A1J9
P4 A3J5
P5 A2P1
P6 A4J1
A2P1 P5
B1P1 A1J12
W1P1 A1J15
W1P2 A2J1
W2P1 A1J11 Exgine Systems Only
W2P2 A3J8 Exgine Systems Only
W3P1 A1J14 Exgine Systems Only
W3P2 A3J2 Exgine Systems Only
W4P1 A3J1 Exgine Systems Only
W4P2 U4J1 Exgine Systems Only
W5J1 EXT 10 MHz
W5P1 A1J13
W5P1 A3J3 Exgine Systems Only
W6P1 A1J13 Exgine Systems Only
W6P2 A3J4 Exgine Systems Only
