NV5/NV3.5 Troubleshooting Manual Wiring/connector lists
Issue 3.2 2014-12-10 Page 4-13
Table 4.7: Wiring List - Ac Distribution Assembly (Nautel Part # 206-5150-01)
Source Destination Wire # Colour Size Remarks
J1-L J2-L - Red 14 Jumper
J1-E (GND) E1 - Grn/Yel 14 Jumper
J1-N J2-N - White 14 Jumper
J2-L J3-L - Red 14 Jumper
J2-E (GND) E1 - Grn/Yel 14 Jumper
J2-N J3-N - White 14 Jumper
J3-L J4-L - Red 14 Jumper
J3-E (GND) E2 - Grn/Yel 14 Jumper
J3-N J4-N - White 14 Jumper
J4-E (GND) E2 - Grn/Yel 14 Jumper
J5-L J6-L - Red 14 Jumper
J5-E (GND) E3 - Grn/Yel 14 Jumper
J5-N J6-N - White 14 Jumper
J6-L J7-L - Red 14 Jumper
J6-E (GND) E3 - Grn/Yel 14 Jumper
J6-N J7-N - White 14 Jumper
J7-L J8-L - Red 14 Jumper
J7-E (GND) E4 - Grn/Yel 14 Jumper
J7-N J8-N - White 14 Jumper
J8-E (GND) E4 - Grn/Yel 14 Jumper
