NV5/NV3.5 Troubleshooting Manual Wiring/connector lists
Page 4-14 Issue 3.2 2014-12-10
Table 4.8: Wiring List - NAA56/01D RF Power Module
Source Destination Wire # Colour Size Remarks
A10TB4-1 A1-B 1 White 16
A10TB4-2 A3-B 2 White 16
A10TB4-3 A5-B 3 White 16
A10TB4-4 A7-B 4 White 16
A10TB5-1 A2-B 5 White 16
A10TB5-2 A4-B 6 White 16
A10TB5-3 A6-B 7 White 16
A10TB5-4 A8-B 8 White 16
A10TB5-5 A9-B 9 White 16
A10TB3-1 A1-A 10 White 22
A10TB3-2 A2-A 11 White 22
A10TB3-3 A3-A 12 White 22
A10TB3-4 A4-A 13 White 22
A10TB3-5 A5-A 14 White 22
A10TB3-6 A6-A 15 White 22
A10TB3-7 A7-A 16 White 22
A10TB3-8 A8-A 17 White 22
A10TB3-9 A9-A 18 White 22
A12-M A10TB2-3 19 White 22 1 Conductor
A12-N E1 19 Shield - Shielded
A12-J A10TB1-1 20 White 22
A12-L A10TB1-3 21 White 22
A12-A A10TB2-1 22 White 22
A12-G A10TB2-2 23 White 22
A12-C A11-K 24 Core 50 ohm coax cable
A12-D A11-L 24 Shield -
A12-E A11-M 25 Core 50 ohm coax cable
A12-F A11-N 25 Shield -
W1P1 W1P2 - Black - Cat.5e Shielded
W2P1 W2P2 - Black - Cat.5e Shielded
