38
Note: Your machine may not match the image. For reference only.
1. Remove screws that attach Console to the Mast. Carefully lift the
Console off the Mast.
2. Disconnect the Data Cable and Heart Rate Cable from the back of
the Console. Set the Console and screws safely aside for reassembly.
Note: Do not let the cables fall down inside the Mast. This step may
require two people.
3. Remove the Handlebar Bracket Cover and set it safely aside for
reassembly.
4. Grasp the section of HR Cable under the Handlebar Bracket and
carefully pull the cable down through the Mast and out of the hole in the
Handlebar Bracket.
Note: Do not let the Data Cable fall down inside the Mast.
To reduce the risk of electrical shock or unsupervised usage of the equipment, always unplug the power cord from the wall outlet and wait 5
minutes before cleaning, maintaining or repairing this machine. Place the power cord in a secure location.
