Nautilus E626 Service Manual

61
NOTICE: It is necessary to remove the Shrouds for this procedure. Refer to the “Replace the Shrouds” procedure.
Note: Your machine may not match the image. For reference only.
1. Carefully remove the Left Shroud. Refer to the “Replace the Shrouds”
procedure in this manual.
2. Carefully disconnect the Power Inlet cable (A) in the Shroud from the
wiring harness (B) on the motor.
To reduce the risk of electrical shock or unsupervised usage of the equipment, always unplug the power cord from the wall outlet and wait 5
minutes before cleaning, maintaining or repairing this machine. Place the power cord in a secure location.
A
B
B
A
Recumbent bike
Upright bike

Nautilus E626 Specifications

General

Bottle holder	Yes
Product color	Black, Grey
Number of programs	29
Maximum user weight	136 kg
Number of resistors	25
Training displayed parameters	Calories, Distance, Time
