40
10. Put the Handlebar in the bracket, adjust the Handlebar to the desired
angle, and install the T-handle through the holes and washers.
NOTICE: Do not crimp the cables.
11. Use the pull cable in the Handlebar Bracket to route the HR cable
through the slot under the Handlebar Bracket to the top of the mast. Fully
tighten the T-handle to keep the Handlebar in position. Push the cover into
position on the Handlebar Bracket.
NOTICE: Do not crimp the cables. Do not let the cables fall down in
the Mast.
12. Connect the cables to the back of the Console and attach the
Console to the Mast.
NOTICE: Do not crimp the cables.
13. Final Inspection
Inspect your machine to ensure that all hardware is tight and components
are properly assembled.
Do not use until the machine has been fully assembled and
inspected for correct performance in accordance with the
Owner’s Manual.
