PARTS LIST
ITEM NO. DESCRIPTION QTY.
1 MAIN FRAME 1
2 REAR STABILIZER 1
3 FRONT STABILIZER 1
4 BOOT SHROUD 1
5 HANDLE BAR MAST 1
6 SEAT 1
7 SEAT POST 1
8 HANDLE BAR ASSEMBLY 1
9 COMPUTER 1
10 COMPUTER LOWER CASE 1
11 WATER BOTTLE CAGE 1
12 REMOTE CAGE CASE 1
13R PEDAL RIGHT 1
13L PEDAL LEFT 1
14R PEDAL STRAP RIGHT 1
14L PEDAL STRAP LEFT 1
15 ADAPTOR 1
16 M8 WASHER 12
17 M8 SPRING WASHER 10
18 M8x1.25x65 SOCKET HEAD CAP SCREW 4
19 COMPUTER CABLE 1
20 HEART RATE WIRE 1
21 M5x0.8x10L PAN HEAD SCREW 4
23 SENSOR CABLE 1
24 M8x1.25x40L SOCKET HEAD CAP SCREW 6
25 POP-PIN 1
26 M8x1.25x40L SOCKET HEAD CAP SCREW 2
27 M4x0.7x10L PAN HEAD SCREW 4
28 M4x0.7x12L PAN HEAD SCREW 4
TOOLS AND HARDWARE
