ASSEMBLY INSTRUCTIONS
NB 2000 UPRIGHT BIKE
STEP 5: Attaching the Handlebar
Attach the handlebar assembly (8) to the handlebar mast (5) using 2 – 40mm
socket head cap screws (26), and 2 - washers (16).
STEP 6: Installing the Computer Console
Plug in the computer cable (19), and the grip heart rate wire (20) into back of the
computer (9).
Attach the computer (9) to the handlebar assembly (8) using 4 - 10mm pan head screws
(27). Be careful not to damage or disconnect computer wires. Then attach the computer
lower case (10) to the computer (9) using 4 – 12mm pan head screws (28).
