Nautilus NS-4000 User Manual

NS-4000
24
SUB-ASSEMBLY
1a Flat / Incline Bench Supporter 1 14574
2a Leg Extension Main Base 1 14573
3a Adjustment Plate 1 14582
4a Round Foot Pad 2 14617
5a 1" Bumper 3 14183
6a Seat Support 1 14580
7a Lever Handle 1 14581
8a Lever Hand Grip -7"L 1 14623
9a Left Leg Extension Arm Support Bar 1 14545
10a Right Leg Extension Arm Support Bar 1 14546
11a Seat Support Bracket 1 14543
12a Back Support Bracket 1 14544
13a Spring 1 14610
14a Hex Bolt 1/2" x 5 1/4"L 6 14521
15a Hex Bolt 1/2" X 4 1/4"L 1 14661
16a Hex Bolt 1/2" x 3"L 1 14377
17a Hex Bolt 3/8" x 5 1/4"L 1 14664
18a Hex Bolt 3/8" x 4 1/4"L 2 14246
19a Hex Bolt 3/8" x 1 1/4"L 1 95786
20a Hex Bolt 3/8" x 1"L with ThreadLock 1 14252
21a Button Head Screw 1/4" x 3/4"L ThreadLock1 14656
22a 1/2" Flat Washer 18 14658
23a 3/8" Flat Washer 9 14233
24a 1/4" Flat Washer 1 14659
25a 1/2" Lock Nut 8 14674
26a 3/8" Lock Nut 4 14234
27a Step Bushing 19.45 x 12.8 x 18h 20 14200
28a 2" X 3" Rectangular End Cap 2 14170
29a Round End Cap 1" 1 14164
30a 2" Square End Cap 3 14162
31a Plastic Sleeve 2"L 1 14618
32a Lever Adjustment Link 1 14644
33a Seat Tube 1 14579
34a Flat / Incline Bench Tube 1 14575
35a 1 1/2" x 2" Rectangular End Cap 1 14168
36a Seat Guard 1 14766
37a Pec Fly Seat Pad 1 14628
38a PanHead Allen Screw 5/16” - 1”L 4 14767
SUB-ASSEMBLY NOT SHOWN
1b "T" Type Pulley Connector 1
2b 1 1/2" Round End Cap 2 14614
3b 1 1/4" Round End Cap 2 14612
4b 1 1/8" Round End Cap 2 14379
5b 1 3/16" x 2 3/8" Rectangular End Cap 1 14613
6b 1 3/4" x 2" Rectangular End Cap 14 14177
7b 1 3/4" x 4" Rectangular End Cap 3 14380
8b 1" Bumper 6 14183
9b 1" Round End Cap 4 14164
10b 1" Square End Cap 2 14611
11b 1/2" Flat Washer 2 14658
12b 1/2" Lock Nut 2 14674
13b 2 3/8" Square End Cap 2 14620
14b 2" Square End Cap 5 14162
15b 2" x 3" Rectangular End Cap 7 14170
16b 2" x 4" Rectangular End Cap 5 14615
17b 3 1/2" Pulley 1 14173
18b 3/8" Flat Washer 32 14233
19b 3/8" Lock Nut 18 14234
20b 4 1/2" Pulley 13 14185
21b 6905 Bearing 2 14271
22b AB Crunch Pivot Shaft 1 14550
23b Allen Screw
(Set Screw) 5/16" x 1/4"L ThreadLock 4 14506
24b Back Adjustment Handle Cover 1 14180
25b Back Adjustment Stop Pin 1 14607
26b Ball Knob Pop Pin 1 14645
27b Bumper 1 14282
28b Button Head Allen Screw 1/4" x 3/4"L ThreadLock 1 14656
29b Cap Head Allen Screw 7/16" x 1 1/2"L 4 14235
30b Glide 5 14616
31b Hand Grip 11"L 2 14622
32b Hand Grip 7"L 4 14623
33b Hand Grip 8 1/8"L 2 14624
34b Hex Bolt 1/2" x 4"L 1 14660
35b Hex Bolt 1/2" x 5 1/4"L 1 14521
36b Hex Bolt 3/8" x 1 3/4"L ThreadLock 1 14670
37b Hex Bolt 3/8" x 2 1/2"L ThreadLock 2 14671
38b Hex Bolt 3/8" x 2 3/4"L ThreadLock 2 14250
39b Hex Bolt 3/8" x 2"L 5 14242
40b Hex Bolt 3/8" x 3"L 4 14245
41b Hex Bolt 3/8" x 4 1/2"L 1 92170
42b Hex Bolt 3/8" x 5"L 1 14663
43b Hex Bolt 3/8" x 6 1/4"L 3 14665
44b Hex Flange Nut 1 14409
45b Leg Press Foot Pad 1 14637
46b Pan Head Allen Screw 3/8" x 1"L 7 14675
47b Pec Fly Pop Pin 1 14213
48b Round Foot Pad 12 14617
49b Screw Bumper 1 14152
50b Selector Stem 4 14204
51b Step Bushing 16.2 x 10 x 12.5h 2 14336
52b Step Bushing 19.45 x 12.8 x 18h 10 14200
53b Step Bushing 31 x 25.1 x 15h 2 14634
54b Step Bushing 31 x 25.1 x 20h 22 14193
55b T Handle Pop Pin - Seat Adjustment 3 14646
56b Press Arm Pop Pin 1 14212
57b Top Weight 4 14205
58b Top Weight Bushing 8 14175
59b V Pulley 4 14186
60b Press Arm Back Adjuster 1 14594
