Nautilus NS-4000 User Manual

NS-4000
4
1 Main Base 1 14552
2Pec Fly Support Upright 1 14553
3 Press Arm Support Upright 1 14554
4 Main Top Frame 1 14555
5Pec Fly Main Frame 1 14596
6Pec Fly Base 1 14597
7Pec Fly Back Adjuster 1 14598
8Pec Fly Top Beam 1 14599
9 Seat Row Frame 1 14604
10 Pec Fly Seat Adjuster 1 14605
11 Pec Fly Mount 1 14600
12 Pec Fly Range of Motion 1 14601
13 Left Pec Fly Handle 1 14602
14 Right Pec Fly Handle 1 14603
15 Backing Plate 1 14548
16 Roller Collar 2 14608
17 Press Arm Main Frame 1 14586
18 Press Arm Base 1 14587
19 Press Arm Seat Frame 1 14588
20 Seat Adjuster 1 14595
21 Press Arm 1 14589
22 Press Arm Top Beam 1 14590
23 Press Arm Range of Motion 1 14591
24 Press Arm Pivot Shaft 1 14549
25 Left Press Arm Handle 1 14592
26 Right Press Arm Handle 1 14593
27 Pulley Cover 2 14541
27a Leg Press Cable Guard 1 14690
28 Leg Press Main Base 1 14556
29 Leg Press Seat Adjuster 1 14557
30 Leg Press Seat Glide 1 14558
31 Leg Press Rear Support 1 14559
32 Leg Press Seat Handle 1 14560
33 Foot Rest 1 14567
34 Cable Guide Upper Bracket 1 14774
34a Cable Guide Lower Bracket 1 14776
35 AB Crunch Arm 1 14561
35a AB Crunch Shaft 1 14550
36 AB Base Support Tube 1 14562
37 Base Connecting Assembly 1 14563
38 AB Crunch Support Upright 1 14564
39 Reinforcement Link 1 14565
40 AB Crunch Bracket 1 14571
41 Leg Press Top Link 1 14566
42 Leg Press Rear Link left 1 14568
43 Leg Press Rear Link right 1 14569
44 Leg Press Front Link left 1 14359
45 Leg Press Front Link right 1 14360
46 Leg Press Power Arm 1 14570
47 Leg Press Foot Plate 1 14572
48 Leg Press Power Link 2 14542
49 Power Link Pivot Shaft 2 14551
50 Leg Press Pivot Shaft 5 14375
51 Leg Ext. Main Frame 1 14678
52 Leg Ext. Arm 1 14583
53 Leg Ext. Base Connector 1 14584
54 Leg Ext. Base Stabilizer 1 14585
55 Leg Ext. Roller Bar 2 14539
56 Seat Back Bench Adjustment 1 14576
57 Leg Curl Handle Right 1 14769
57a Leg Curl Handle Left 1 14577
58 Seat Handle 2 14578
59 Guide Rod 8 14540
60 Top Weight Assembly 4 14679
61 Weight Plate 76 14342
62 Pulley Plate 2 14547
63 Pulley Bracket 1 14606
64 Floating Pulley Bracket 1 14121
65 Double Floating Pulley Bracket 1 14677
66 Weight Stack Bottom Plate 4 14106
67 Weight Stack Cushion 8 14176
68 Leg Press Station Shroud 1 14640
69 Press Arm Station Shroud 1 14641
70 Pec Fly Station Shroud 1 14642
71 Press Arm Back Pad 1 14633
72 Press Arm Seat Pad 1 14632
73 Pec Fly Back Pad 1 14629
74 Pec Fly Seat Pad Assembly 1 14768
75 Leg Press Back Pad 1 14626
76 Leg Press Seat Pad 1
77 AB Crunch Pad 1 14627
78 Leg Extension Back / Bench 1 14631
79 Leg Extension Seat Pad 1 14630
80 Pec Fly Roller Pad 2 14638
81 Leg Extension Roller Pad 4 14639
82 2 3/8" Plastic Washer 8 92058
83 Plastic Cap 2 14158
84 Leg Ext. Roller End Cap 4 14165
85 Guide Rod Holder 4 14174
86 Leg Ext Bumper 1 14619
87 1 3/8" Plastic Washer 2 14621
88 6" Pulley 1 15848
89 Leg Extension Station Shroud 1 14640
90 4 1/2" Pulley 21 14185
91 T Handle Pop Pin 1 14646
CABLES
92 Leg Extension Cable - 193”L 1 14647
93 Pec Fly Cable - 114” L 1 14648
94 Primary Cable - 127.5”L 1 14649
95 Low Row Cable - 284.5”L 1 14650
96 Secondary Cable - 68”L 1 14651
97 Pec Fly Cable - 27"L 1 14652
98 Pec Fly Cable - 28.25"L 1 14653
99 Leg Press Cable - 281.75”L 1 14654
100 Pull Down Cable - 277”L 1 14655
101 Guide Cable - 66”L 1 14778
HARDWARE
101a Hex Bolt - 1/2" x 4"L 1 40000
102 Hex Bolt - 1/2" x 2 3/4"L ThreadLock 3 14666
103 Hex Bolt - 1/2" x 2 3/4"L 2 14526
104 Hex Bolt - 1/2" x 3/4"L ThreadLock 2 14667
105 Hex Bolt - 3/8" x 6 1/4"L 1 14665
106 Hex Bolt - 3/8" x 5"L 4 14663
107 Hex Bolt - 3/8" x 4 1/2"L 2 92170
108 Hex Bolt - 3/8" x 4 1/4"L 4 14246
109 Hex Bolt - 3/8" x 4"L 6 14247
110 Hex Bolt - 3/8" x 3 1/2"L 4 14523
111 Hex Bolt - 3/8" x 3 1/4"L 9 14279
112 Hex Bolt - 3/8" x 3"L 24 14245
113 Hex Bolt - 3/8" x 2 3/4"L 2 14241
114 Hex Bolt - 3/8" x 2 1/2"L 2 14240
115 Hex Bolt - 3/8" x 2 1/2"L ThreadLock 1 14671
116 Hex Bolt - 3/8" x 2 1/4"L 3 14265
117 Hex Bolt - 3/8" x 2"L 7 14242
118 Hex Bolt - 3/8" x 1 3/4"L 4 14239
119 Hex Bolt - 3/8" x 1 3/4"L ThreadLock 3 14670
120 Hex Bolt - 3/8" x 1 1/4"L 18 95786
121 Hex Bolt - 3/8" x 1 1/4"L ThreadLock 1 14669
122 Hex Bolt - 3/8" x 1"L 8 92161
123 Button Head Screw - 3/8" x 1"L 1 14251
124 Hex Bolt - 3/8" x 1"L ThreadLock 6 14252
125 Cap Head Screw 1/4" x 1"L ThreadLock 8 15882
126 Button Head Screw 1/4" x 3/4"L ThreadLock 1 14656
127 Button Head Screw 3/8" x 3/4"L ThreadLock 34 15881
128 1 11/32 x 1/2" Flat Washer 2 14657
129 1/2" Flat Washer 12 14658
130 3/8" Flat Washer 195 14233
131 1/4" Flat Washer 1 14659
132 Half Circle Washer 4 14672
133 1/2" x 15/32t Lock Nut 6 14674
134 3/8" Lock Nut - Thin 1 14528
135 3/8" Lock Nut 76 14234
136 Shim Washer 2 14156
137 Pan Head Screw 1 14609
138 Pulley Spacer 1"L 4 14196
139 Pulley Spacer 1/2"L 4 14198
140 Step Bushing 25/32H 4 14635
141 Step Bushing 11/16"H 4 14636
142 Set Screw 3/8" x 3/8” ThreadLock 8 14676
ACCESSORIES
143 Handle Strap with 2 rings 4 14384
144 Cable Clip 4 92054
145 Tethered Weight Selector Pin 4 14643
146 M4 Allen Wrench 1 14680
147 M5 Allen Wrench 1 14532
148 M6 Allen Wrench 1 14533
149 M8 Allen Wrench 1 14534
# Gym Components Qty. Part # # Gym Components Qty. Part #
