9
step
6
Step #6 Materials:
#Component Qty
38 Locking Roller Bar 1
39 Roller Bar 1
40 Plastic Washer 2
41 PU Roller 2
42 8"L Foam Roller 2
43 PU Roller End Cap 2
44 Round End Cap 2
NS-700
A. Slide Roller Bar (39) through the Leg Extension Tube.
Either of the bottom two holes can be used depending
on the best fit for the user.
B. Slide a Plastic Washer (40) followed by a Foam Roller
(42) on the Roller Bar (39). Press the Roller End Cap
(44) firmly into the Roller Bar (39). Repeat for the
opposite side.
C. Slide the Locking Roller Bar (38) through the Leg
Extension Tube as shown making sure that it is
centered. Slide the Eccentric Roller (41) on the Locking
Roller Bar (38). Press the Locking Roller End Cap (43)
into the Locking Roller Bar (38). Repeat for the
opposite side making sure that the Eccentric Rollers are
aligned.
