Adjust the Belt Tension on the Nautilus
™
U614/U616 and
R614/R616 Bikes
Skill Level: II
8008063.081519.B
Replacement Procedure
NOTICE: This document provides instructions for the adjustment of the Drive Belt tension on the Nautilus
™
U614 and U616 (Model Year 2014) and U616 (Model Year 2017)
Upright Bikes, and R614 and R616 (Model Year 2014) and R616 (Model Year 2017) Recumbent Bikes.
If you need assistance, please contact Customer Service (if purchased in US/Canada) or your local distributor (if purchased outside
86&DQDGD7R¿QG\RXUORFDOGLVWULEXWRUJRWRZZZQDXWLOXVLQWHUQDWLRQDOFRP
Tools Required (not included)
#2 Phillips screwdriver 15mm open end wrench
6PDOOÀDWKHDGVFUHZGULYHU PPVRFNHWDQGZUHQFK
Pedal wrench or 15mm open end
wrench (U614/R614)
or crank puller (U616/R616)
™
™
Nautilus, Inc., www.NautilusInc.com, 5415 Centerpoint Parkway, Groveport, OH 43125 U.S.A. - Customer Service: North America (800) 605-3369, csnls@nautilus.com | outside U.S.
www.nautilusinternational.com | © 2014 Nautilus, Inc. | Nautilus and the Nautilus logo are trademarks owned by or licensed to Nautilus, Inc., which are registered or otherwise protected by
common law in the United States and other countries. | ORIGINAL DOCUMENT - ENGLISH VERSION ONLY
This icon means a potentially hazardous situation which, if not avoided, could result in death or serious injury. Read and understand
all Warnings on this machine.
,PSRUWDQW6DIHW\,QVWUXFWLRQV%HIRUHVHUYLFLQJRUXVLQJWKLVHTXLSPHQWREH\WKHIROORZLQJZDUQLQJV
Read and understand the Service Manual before working on the machine. Failure to obey the instructions and safety warnings could
cause injury to the service technician or bystanders.
Disconnect all power to the machine before you service it.
• Keep bystanders and children away from the product being serviced at all times.
0DNHVXUHWKDWWKHUHSDLULVGRQHLQDQDSSURSULDWHZRUNVSDFHDZD\IURPIRRWWUDႈFDQGH[SRVXUHWRE\VWDQGHUV
• Some components of the equipment can be heavy or awkward. Enlist the service of a second person when you do
maintenance steps involving these components. Do not try to do heavy or awkward steps on your own.
• If replacement parts are necessary, use only genuine replacement parts and hardware supplied by Nautilus. Failure to use
genuine replacement parts can cause a risk to users, keep the machine from operating correctly and void the warranty.
• Be sure that all warning stickers and instructional placards applied to the product stay present and in good condition when
doing maintenance or replacing components. If at any time the Warning labels become loose, unreadable or dislodged,
replace the labels. If purchased in US/Canada, contact Customer Service for replacement labels. If purchased outside US/
Canada, contact your local distributor for them.
'RQRWWU\WRFKDQJHWKHGHVLJQRUIXQFWLRQDOLW\RIWKHPDFKLQHEHLQJVHUYLFHGDVWKLVFDQDGYHUVHO\DႇHFWXVHUVDIHW\
• Do not put the machine back in service until all shrouds, instructions, warning labels and correct functionality have been
YHUL¿HGDQGWHVWHGIRUFRUUHFWSHUIRUPDQFH
