Nautilus R628 Service Manual

56
7. 8VLQJDPPKH[ZUHQFKORRVHQDQGUHPRYHWKHKDUG-
ware that attaches the Seat Adjustment Handle to the seat
slider assembly. Remove the Seat Adjustment Handle. Set
the hardware and Seat Adjustment Handle safely aside.
8. Carefully remove the Top Cap from the seat slider
bracket, and disconnect the Resistance and Heart Rate
Cables.
9. 8VLQJDPPKH[ZUHQFKUHPRYHWKHEROWVIURPWKH
bracket arms at the front of the Seat Frame. Using a 6mm
KH[ZUHQFKUHPRYHWKHEROWVIURPWKHEDFNRIWKH6HDW
Frame. Remove the Seat Frame Assembly. Set the hardware
and Seat Frame Assembly safely aside.
NOTICE: Do not crimp any cables.This step may require
two people.
