7
Item Qty Description Item Qty Description
1 1 Frame 12 1 Seat Bottom
2 1 Front Stabilizer 13 1 Console Mast
3 1 Rear Stabilizer 14 1 Top Shroud
4 1 Seat Rail End Cap 15 1 Console
5 1 Seat Frame Assembly 1 Console Pivot Shroud
1 Top Cap 17 1 Right Pedal
7 2 Seat Pivot Shroud 18 1 Left Pedal
8 1 Seat Back 19 1 Water Bottle Holder
9 1 Seat Recline Handle 20 1 Power Cord
10 1 Shock Shroud 21 1 MP3 Cord
11 1 Seat Adjustment Handle 22 1 Heart Rate Chest Strap
PARTS
20
15
21
5
12
6
4
7
8
1
9
10
3
11
18 (L)
2
17 (R)
14
13
19
16
22
To Next Page
