Nautilus R628 User Manual

9
ASSEMBLY
1a. Attach Stabilizers to Frame
Note: Hardware(*) is pre-installed on the stabilizers and not on Hardware Card. Make sure transport wheels on
the front stabilizer point forward.
1b. Attach the Seat Rail End Cap to the Frame Assembly
3
*
6mm
*
*
X2
2
*
6mm
*
*
X2
1
4
