148
18. Slightly push the walking deck forward toward the console, and then
push the Deck Release Handle until the locking tube releases and you can
pull the walking deck away from the console. Hold up the rear of the walk-
ing deck, and move to the side of the machine.
Keep clear of the movement path of the walking deck.
19. The hydraulic lift is set up to drop gradually. Hold onto the walking
deckuntilapproximately2/3ofthemovementdown.Makesurethatyou
use proper lifting technique; bend your knees and keep your back straight.
Be aware that the walking deck can possibly drop quickly in the last part of
the movement.
20. Re-install all remaining parts that were removed in reverse order.
Note: When re-attaching the Console Backing, be sure to attach the hard-
waremarkedwiththe(*)rst,thenthehardwarewiththe(**),followed
by the remaining hardware.
21. Final Inspection
Inspect your machine to ensure that all hardware is tight and components
are properly assembled.
Do not use until the machine has been fully assembled and
inspected for correct performance in accordance with the
Owner’s Manual.
*
*
**
**
