SECTION3–INSTRUMENTS,INDICATORS,ANDSWITCHES

OilPressureGauge

Figure20Oilpressuregauge.

Theengineoilpressuregaugeindicatesoperatingoilpressure.

Theengineoilpressureindicatorlampandalarmwillbe

activatedwhenoilpressurefallsbelowacceptablelevels.

Shutdowntheengineimmediatelyifthelampandalarmare

activated.Contactanauthorizedserviceproviderimmediately

tohavetheproblemcorrected.

LubricationOilPressure

LubeOilPressure

Atnormaloperatingtemperature

Lowidle15psi(103kPa)

Highidle50psi(344kPa)

CAUTION

Topreventenginedamage,shutdownengine

immediatelyifthegaugeuctuatesordrops

below276kPa(50psi)underload.Correctthe

problem.

Page41
