SECTION5–MAINTENANCESCHEDULEANDSERVICEPROCEDURES

CHARGEAIRCOOLER(CAC)

ServiceInterval:BeforeEngineOperation

WARNING

Topreventpersonalinjuryordeath,shutdown

engine,setparkingbrake,andinstallwheel

chocksbeforeinspectingtheChargeAirCooler.

1.InspectChargeAirCooler(CAC)corefordebris,damaged,

andcloggedexternalns.

2.Beforestartingengineremoveanydebrisblockingthecore.

EXTERNALLEAKAGE

ServiceInterval:BeforeEngineOperation

WARNING

Topreventpersonalinjuryordeath,shutdown

engine,setparkingbrake,andinstallwheel

chocksbeforeinspectingforexternalleakage.

1.Checkforthefollowing:

•Crackedhoses

•Looseclamps

•Coolantstains

•Oilstains

•Fuelstains

•Leakageatwaterpump(wetnessfromtheweephole

isnormal)

2.Correctproblems.

AIRCLEANERRESTRICTION

ServiceInterval:BeforeEngineOperation

Figure29Aircleanerrestrictionindicator

Page64
