SECTION1–ENGINESYSTEMS

EngineSpecications

MaxxForce

DT,9,&10Engines

EngineConguration4stroke,inlinesixcylinderdiesel

Advertisedbrakehorsepower@rpmSeeengineemissionlabel

Peaktorque@rpmSeeengineemissionlabel

Displacement

•MaxxForce

DTengines

•MaxxForce

9and10engines

7.6L(466in

)

9.3L(570in

)

Compressionratio

•MaxxForce

DTengines

•MaxxForce

9and10engines

16.9:1

16.5:1

Stroke

•MaxxForce

DTengines

•MaxxForce

9and10engines

119mm(4.68in)

146mm(5.75in)

Bore(sleevediameter)116.6mm(4.59in)

Firingorder1-5-3-6-2-4

AspirationDualturbochargedandchargeaircooled

CombustionsystemDirectinjectionturbocharged

FuelsystemElectro-hydraulicinjection

Page15
