20
2. From the corner cable access hole, route the cable down the Core Cabinet wall and
down the bottom exit hole, as shown in the image below.
Note
Pass the cable through cable clamps and secure the cable on the bridge
lances using cable ties.
3. Connect the cable to the PoE Switch.
