Routing the Cables: 7358 R6L Plus
To route the Tri-Light/Lane Light Cable and the LAN Cable in the 7358 unit, follow these
steps:
1. Route the Tri-Light/Lane Light Cable by doing the following:
a. From the Tri-Light/Lane Light Pole, route the cable up into the Upper Cabinet.
Note
Apply enough cable slack to prevent the cable from being stretched
during installation or removal procedures.
