Installation Procedure
To install the IPCamera Field Upgrade (D-Vitec), follow these steps:
Note
Ensure that the NCR Customer Helpdesk is informed when the Tri-Light/Lane
Light with IPCamera is installed in the store.
1. Remove the existing Tri-Light/Lane Light Assembly. For more information, refer to
Removing the Tri-Light/Lane Light (R6) on the next page.
2. Install the IP Camera (D-Vitec) to the Tri-Light/Lane Light Assembly, refer to Installing
the IP Camera on page10.
3. Install the Tri-Light with IPCamera Assembly. For more information, refer to
Installing the Tri-Light/Lane Light with IPCamera Assembly on page13.
4. Configure the Camera Settings. For more information, refer to Configuring the
Camera Settings on page52.
