-44-
Service Manual CP-785F
. If the TV set was on normal run mode before switching off, the microcontroller delivers
horizontal drive voltage at pin 33 and picture appears on screen.
. If the TV set was on stand-by mode before switching off, the microcontroller switches TV set to
stand-by mode, decreasing power pin voltage (pin 63). This matter will be explained on
paragraph 5-9-2-b.
