LOC PART NAME PART Code PART Description Remark
A001 PCB UNION 4859811060 246X246
CS01 C ELECTRO CEXF1H479V 50V RSS 4.7MF (5X11) TP
CS02 C ELECTRO CEXF1H479V 50V RSS 4.7MF (5X11) TP
DS01 DIODE ZENER DMTZJ5R6B- MTZJ 5.6B
HP01 JACK PHONE 4859105240 LGT1516-0100
JPA02 JACK PIN BOARD 4859105450 YSC03P-4120-9S
JS01 WIRE COPPER 85801065GY AWG22 1/0.65 TIN COATING
P603 CONNECTOR 4850709S03 YH025-09+YST025+ULW=400
RS01 R CARBON FILM RD-2Z151J- 1/2 150 OHM J
RS02 R CARBON FILM RD-2Z151J- 1/2 150 OHM J
RS04 R CARBON FILM RD-AZ473J- 1/6 47K OHM J
RS05 R CARBON FILM RD-AZ473J- 1/6 47K OHM J
6-3. Control Assembly Parts Lists
Service Manual CP-785F
-64-
LOC PART NAME PART Code PART Description Remark
RA07 R CARBON FILM RD-AZ102J- 1/6 1K OHM J
RA08 R CARBON FILM RD-AZ750J- 1/6 75 OHM J
RA11 R CARBON FILM RD-AZ750J- 1/6 75 OHM J
RA16 R CARBON FILM RD-AZ910J- 1/6 91 OHM J
RA40 R CARBON FILM RD-AZ102J- 1/6 1K OHM J
RA41 R CARBON FILM RD-AZ102J- 1/6 1K OHM J
SCT1 SOCKET CRT 4859303530 PCS629-03C
48592303830 ISMG94S COMPATIBLE( )
SD2 RETA PCB 4853747800 NYLON 66
SF01 FILTER SAW 5PK3953M K3953M
SF02 FILTER SAW 5PK9650M K9650M
SW700 SW TACT 5S50101090 THVH472GCA
SW701 SW TACT 5S50101090 THVH472GCA
SW702 SW TACT 5S50101090 THVH472GCA
SW703 SW TACT 5S50101090 THVH472GCA
SW704 SW TACT 5S50101090 THVH472GCA
SW706 SW TACT 5S50101090 THVH472GCA
SW801 SW POWER PUSH 5S40101143 PS3-22SP (P.C.B)
T401 TRANS DRIVE 50D19A1 - TD-19A1
T402 FBT 50H0000247 FFA64028L
T801 TRANS SMPS 50M4950A8- TSM-4950A8
U100 TUNER VARACTOR 4859721530 DT5-BF18D N
X502 CRYSTAL QUARTZ 5XEX12R00E HC-49/U 12.000MHZ 30PPM TP
X601 CRYSTAL QUARTZ 5XEX18R43E HC-49/U 18.432MHZ 30PPM TP
Z501 FILTER CERA 5PXXT5R5MB XT 5.5MB-TP
