-50-
Service Manual CP-785F
6 - Service Parts List
6-1. Parts List
LOC PART NAME PART Code PART Description Remark
ZZ100
TRANSMITTER REMOCON
48B4744N08 R-44N08 (AA) With Text(RD-D90)
00030 BATTERY 4850Q00810 R6P/LN
ZZ120 COVER BACK AS PTBCSHK016 DTQ-29U1SC
ZZ131 CRT GROUND NET 48519A6410 2902S-1015-1P
ZZ132 COIL DEGAUSSING 58G0000149 DC-29SF
V901 CRT 4859641561 A68QCU770X58 M50
ZZ200 MASK FRONT AS PTFMSJK016 DTE-29U1
P601A CONNECTOR 4850704S32 YH025-04+YRT205+ULW900500
SP01 SPEAKER 4858311110 12W 8 OHM SP-58126F
SP02 SPEAKER 4858311110 12W 8 OHM SP-58126F
ZZ290 PCB MAIN MANUAL AS PTMPMSD913 DTE-29U1TH
ZZ300 PCB UNION AS PTUNSWD913 DTE-29U1TH
is safety component, so it must be used the same component.
is a recommendable part for stock.
In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Prats Price List) in Service information Center (http://svc.dwe.co.kr)
Caution
Caution
