Service Manual CP-785F
1-1 Specifications
1 - Main Features
1-2 External Teminals
1-2-1 Input 1 : (The Rear Side) RCA
TV standard PAL, - B/G, H, NTSC(AV Only)
Sound system NICAM B/G
FM 2Carrier B/G
Power consumption 116W approx.
Sound Output Power 5W x 5W (at 60% mod, 10% THD)
Speaker 7W 8 ohm x 2
Teletext system 10 pages memory FASTEXT (FLOF or TOP) : Option
Aerial input 75 ohm unbalanced
Channel coverage Off-air channels, S-cable channels and hyperband
Tuning system frequency synthesiser tuning system
Visual screen size 68 Cm
Channel indicatio On Screen Display
Program Selection 100 programmes
Aux. terminal INPUT1(RCA) : Audio / Video In.
INPUT2(RCA) : Audio / Video In
OUTPUT(RCA) : MONITOR OUT
DVD:Y/Cr/Cb/Audio in
Headphone jack (3.5 mm) on the right front of cabinet
Remote Control Unit R-44N08(RD-D90) for with Teletext
Pin Signal Matching value
1(Yellow) Video Input 1.0 Vpp+/- 3dB, Impedance 75 ohm
2(White) Audio Input Left 0.5 Vrms, Impedance > 10k ohm
3(Red) Audio Input Right 0.5 Vrms, Impedance > 10k ohm
1-2-2 Input2 : (The right Side) RCA
Pin Signal Matching value
1(Yellow) Video Input 1.0 Vpp+/- 3dB, Impedance 75 ohm
2(White) Audio Input Left 0.5 Vrms, Impedance > 10k ohm
3(Red) Audio Input Right 0.5 Vrms, Impedance > 10k ohm
